Lennox Hearth SOLANA-BN User Manual
Page 24
24
Item #
Description
Cat. No.
1
Refractory Baffle
PR-SR2028
2
Back Refractory
PR-SR2027
3
Right Side Refractory
PR-SR2025D
4
Left Side Refractory
PR-SR2025G
5
Bottom Refractory
PR-SR1722
6
Front Refractory Ash Lip
PR-SR2026
7
Log Support Grate
H7706
8
Top Louver
PR-SR15P
9
Bottom Louver
PR-SR15P
10
Louver Hinges
PR-PIVOT
11
Rigid Firescreen (Right)
PR-PARETIND-1
12
Rigid Firescreen (Left)
PR-PARETING-1
13
Black Door (Left)
H7708
14
Black Door (Right)
H7707
15
Brushed Nickel Plated Door (Left)
H7710
16
Brushed Nickel Plated Door (Right)
H7709
17
Wooden Handle
PR-SAC83
18
Touch-up Paint, Aerosol, Black Metallic
SBMB6309
70K99
REPLACEMENT PARTS LIST - SOLANA™
u
Note: To order the complete gasket set to seal one door, order 1 each
P/N PR-COGR2035 (31") and 1 each P/N PR-COGR2035A (16").
v
Note: To order a complete gasket set to seal one glass on a nickel plated
door, order one each P/N PR-ISO2938 , P/N PR-ISO2939 and P/N PR-ISO2750.
Contact an Authorized Lennox Hearth Products dealer to obtain any of
these parts. Never use substitute materials not approved by Lennox
Hearth Products. Use of non-approved parts can result in poor perfor-
mance and safety hazards.
Item #
Description
Cat. No.
19
Ceramic Glass Panel
PR-VC10
---
Thermostatic Disc Control, Blower
VTU
20
Door Gasket, 31" see note below
u
PR-COGR2035
21
Door Gasket, 16" see note below
u
PR-COGR2035A
---
Horizontal Glass Gasket (for black doors)
PR-SR1685A
---
Vertical Glass Gasket (for black doors)
PR-SR1685B
---
Upper Glass Gasket (for nickel plated doors)
v
PR-ISO2938
---
Side Glass Gasket (for nickel plated doors)
v
PR-ISO2939
---
Lower Glass Gasket (for nickel plated doors)
v
PR-ISO2750
22
Damper (plate, pivot, rod and counter-weight)
PR-SR2798
