Getting to Know the EtherFast
10/100 CardBus PC Cards
Link The LED will illuminate when the card is sucessfully
connected to a network.
Act The Activity LED will flicker when data is being transmit
ted or received over the network.
10/100 This LED will be illuminated when the card is operating at
100Mbps; dormant when operating at 10Mbps.
The RJ-45 Port is where you will connect your Category 3 or 5 network
cabling. See page 48 for detailed information on network cabling.
EtherFast ® 10/100 CardBus PC Cards
5
Linksys Instant EtherFast ® Series
4
• EtherFast 10/100 CardBus PC Card (PCM200 v2 shown)
• One Driver Disk
• One User Guide and Registration Card
Package Contents for the EtherFast
10/100 CardBus PC Cards
LEDs
The RJ-45 Port
