Linksys PCMPC200 v2 - Manual (Page 15)

EtherFast ® 10/100 CardBus PC Cards
3. Click on the Select from list... button to select a network adapter.
4. Select the EtherFast 10/100 CardBusPC Card II, click on the Have Disk
button. Insert the Driver Disk into the floppy drive. Type “a:\” into the
box on your screen and hit OK.
5. When the following window appears, select Linksys EtherFast 10/100
CardBus PC Card Adapter II, click OK.
25
Linksys Instant EtherFast ® Series
24
Windows NT 4.0 Installation and
Setup
The following instructions will set up an NT 4.0 server/workstation on your
PC. You should have your original Windows NT CD-ROM handy during the
installation, as you might be asked to supply it.
To install the network driver for an NT 4.0 Server or Workstation
1. Log into Windows NT as a network administrator.
2. Click on Start, Settings, Control Panel, and then double-click on the
Network icon.
3. If you have not previously installed Windows NT networking on your
computer, a message will appear that reads: Windows NT Networking is
not installed. Do you want to install it now?
• If you see this message, click Yes to install NT networking along with the
EtherFast Card's network driver, and continue with step 1 below.
• If you don't see this message, NT networking is already installed. Skip to
step 1 on page 30.
1. After clicking on Yes, the Network Setup Wizard window will appear.
2. Put a checkmark next to the Wired to the network option. Click Next.
Installing NT Networking & the EtherFast Card Driver
Overview
N No otte e:: Screen shots used in this Installation and Setup section are
from installation of the standard EtherFast 10/100 CardBus PC
Card (PCMPC200 v2). If you are installing the EtherFast 10/100
Integrated CardBus PC Card (PCM200 v2), the installation process
will be unchanged, however, the product name will be different.
