Page 66
TROUBLESHOOTING AND REPAIR
F-32
F-32
POWER MIG 200
1. Place the new wire drive assembly into its
proper position.
2. Connect plug J4.
3. Maneuver assembly back into its original
position.
4. Replace all mounting screws previously
removed.
5. Using a 3/4” nut driver, replace the thick
black lead previously removed.
6. Reconnect the gas hose to the wire drive
assembly.
7. Close case wrap around cover.
WIRE DRIVE MOTOR ASSEMBLY REPLACEMENT (Continued)
