TABLE OF CONTENTS
Safety Rules ......................................Page 2
Locating the Name Plate ...................Page 2
Introduction ......................................Page 3
Parts Required .................................Page 3
Optional Equipment ...........................Page 3
Operating The Ladera™ Fireplace ......Page 3
Fuel ...................................................Page 3
Starting And Maintaining A Fire ........Page 4
Combustion Control .........................Page 4
Refueling For Best Performance .......Page 4
Smoking – Causes And
Troubleshooting ..............................Page 4
Important Cautions ...........................Page 5
Maintaining Your Fireplace ...............Page 5
Creosote ............................................Page 5
Chimney Maintenance .......................Page 5
Dealing With A Chimney Fire .............Page 5
Top Baffle Removal ...........................Page 5
Finish Door Casing Care ....................Page 5
Disposing of Ashes ...........................Page 6
Refractory Installation .......................Page 6
Door Removal ...................................Page 6
Door Adjustment ...............................Page 6
Glass Care - Replacement .................Page 7
Glass Care - Cleaning ........................Page 7
Gasket Replacement ........................Page 7
Fireplace Installation ........................Page 7
Locating The Ladera Fireplace ...........Page 7
Optional Cast Facade Installation ......Page 8
Hearth Extension Requirements .......Page 8
Framing Dimensions .........................Page 9
Nailing Flanges .................................Page 10
Facing ..............................................Page 10
Fireplace Blower ................................Page 11
Hot Air Ducting Installation ..............Page 11
Gravity Kit .........................................Page 11
Central Forced Air Kit ............................Page 12
Outside Air Kit ..................................Page 13
Chimney System ...............................Page 14
Chimney Installation Notes ...............Page 14
Chimney Installation Instructions ......Page 15
Offset Chimney Installation ...............Page 16
Angled Wall Radiation Shield ............Page 18
Chimney Support Installation ............Page 19
Chimney Chase And
Multiple Terminations......................Page 19
Masonry Application Instructions .....Page 20
Installation Accessories ....................Page 21
Replacement Parts ...........................Page 22
Specifications ....................................Page 22
Clearance to Combustibles ...............Page 22
Chimney Components Lists ..............Page 23
Product Reference Information .........Page 26
THE FIREPLACE
INTRODUCTION
The Ladera wood-burning fireplace is an energy
efficient, heat circulating, closed combustion
fireplace. You will receive a lifetime of comfort
and enjoyment from your fireplace provided it is
installed, maintained and operated properly.
s Please read these instructions and retain
this manual for future reference.
s Before beginning the fireplace installation,
consult the local authorities to obtain your
building permit and check your local building
codes. Install the fireplace only as described
in these instructions and using only IHP
components.
s 4HIS lREPLACE HAS BEEN TESTED FOR #!.5,#
3
- AND !.3)5, UNDER REPORT
number 3151759. It has also been tested
for EPA 40 C.F.R Part 60, section 60.532(b).
Certificate number 706 .
s The Ladera fireplace is NOT intended for use
with a gas log set. Do not use a fireplace
insert or any other product with this fireplace
unless it is specified by IHP for use with this
appliance. Failure to follow these instructions
will void the certification and the warranty
of the fireplace and may result in an unsafe
installation.
s 4HESE APPLIANCES ARE DESIGNED TO PROVIDE
supplemental heat to the immediate area
only. Therefore, it is advisable to have an
alternate heat source when installed in a
dwelling.
s 4HESE APPLIANCES ARE ./4 APPROVED FOR
Manufactured Home installations.
PARTS REQUIRED
Fireplace Model Ladera
s v DIAMETER CHIMNEY * - Model ASHT+,
S-2100+, HT6000+, HT6103+ or AC
manufactured by Security Chimneys Inter-
national™ only.
OR
s v DIAMETER CHIMNEY * - Model ASHT and
HT6103 manufactured by Security Chimneys
International™ only.
6” and 7” Chimneys Includes:
- Chimney lengths
- Elbows (where necessary)
- Associated components as per these
installation instructions
s $ECORATIVE $OOR (included in the fireplace)
s 5:9 BLOWER )NCLUDED W&IREPLACE
OPTIONAL EQUIPMENT
Order Separately - See Pages 21 through 24
s !DDITIONAL %QUIPMENT OPTIONAL
- AC Chimney Starter Section * and
AC Chimney *
- Outside Air Kit
(required if using AC Chimney)
- Chimney Adaptor 7 inch (6AW7 * )
(If you choose to use 7 inch ASHT * or
HT6103 * chimney)
- Gravity Venting System
- Rigid Firescreen
- Forced Air Kit X
- Cast Facade Kit
"LOWER 3PEED #ONTROL 6257
- Blower Thermodisc Heat Switch
#ONTROL 645
- Outside air kit
X Not tested under EPA certification. If in-
stalled, this appliance no longer qualifies
for EPA certification.
OPERATING THE LADERA™ FIREPLACE
Fuel
53% 3/,)$ .!452!, 7//$ &5%, /.,9
The Ladera fireplace is designed to work best
when fueled with dry seasoned natural wood
only. Hardwoods are preferred to softwoods
since the energy content of wood is relative to
its density. Hardwoods will result in a longer
burning fire and less frequent refueling. A
moisture content of 15% to 20% (seasoned)
is recommended. Wood that has been cut and
split and let to dry under a cover for a period
of one year will usually meet that criteria. The
required drying time will vary depending on the
climate. Wood that is packed tight together will
take longer to dry. Seasoned wood is darker in
color than wet wood and will have visible cracks
in the grain on the ends. Excessively wet wood
will be difficult to burn and will result in lower
efficiency, increased creosoting and deposits on
the glass and in the chimney. Excessively dry
wood will burn well but will also have higher
emissions and shorter burning time.
Do not burn scrap or garbage, treated wood or
wood such as driftwood from the ocean which
has been exposed to salt or other chemicals.
Salt or chemicals can corrode the firebox and
chimney. Do not burn large amounts of paper,
cardboard, Christmas tree branches or building
construction materials. Intense firing with these
materials may overheat the fireplace, causing
damage to the unit, a fire or even possibly ignit-
ing a chimney fire if the chimney is creosoted.
Burning unapproved fuel, resulting in excessive
pollutants being emitted, may be prohibited and
subject to a fine or other penalty by the authority
having jurisdiction in your area.
0ROCESSEDlRELOGSCANBEUSED5SEONLYlRELOGS
that have been evaluated for the application
of fireplace and refer to firelog warnings and
caution markings on packaging prior to use.
#/.'2!45,!4)/.3
When you purchased your new fireplace, you joined the ranks of thousands of individuals
whose answer to their home heating needs reflects their concern for aesthetics, efficiency
and our environment. We extend our continued support to help you achieve the maximum
benefit and enjoyment available from your new fireplace.
Thank you for selecting a IHP fireplace as the answer to your home supplemental heat-
ing needs.
* Available from Security Chimneys™
3
