CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe
installation;
Side wall: 17” (324 mm) measured from the fireplace side
Ceiling: 6’ 8” (2,032 mm) measured from the base of the fireplace
Fireplace enclosure:
Bottom: 0”
Side: 0’’ to spacer
Back: 0’’ to spacer
Top: Do not fill the space above the fireplace with any material
(Except the wood framing. See Page 9, Figure 8)
Chimney: 2” (50mm)
Mantel: 39’’ (990mm) measured from the base of the fireplace.
SPECIFICATIONS REPLACEMENT PARTS LIST
Cat. No. Model Description
H7162 Ladera-BK Ladera EPA Wood-Burning Fireplace
Product Reference Information
Weight 215 lbs
Height
v
Width
v
Depth
v
Firebox W x H x D - measured in front
v X
v X v
Chimney Weight ASHT* (6” dia) 6.25 lb per linear foot
Chimney Weight AC* (6” dia.) 3.25 lb per linear foot
Chimney weight S-2100+* (6” dia.) 10.8 lb per linear foot
Ladera™ Replacement Parts
Description Part/Cat. No.
Andiron (2 pieces) PR-SR2897
Bottom refractory PR-SR2825
Back refractory PR-SR2826
Left side refractory PR-SR2828
Right side refractory PR-SR2827
Front refractory (2 pieces) PR-SR2829
Secondary air tube (back) PR-SR2906
Secondary air tube (middle or front) PR-SR2830
Tube lock (2 pieces) PR-SR2873
Baffle ceramic PR-ISO2884
Fireplace left side PR-SR2848
Fireplace right side PR-SR2849
Fireplace top PR-SR2847
Fireplace back PR-SR2846
Top flex protector PR-SR2877
Door wooden handle PR-SR2903
Door locking mechanism PR-SR2855
Door hinges PR-SR1933
Ceramic glass PR-SR2899
Gasket, glass PR-SR1685H
Gasket, door PR-SR1823O
Blower 02
5:9
Door, complete black PR-SR2898
Touch-up Paint, Aerosol, Black Metallic SBMB6309 H8159
"LOWER #&- FOR CENTRAL FORCED AIR KIT ")3:9 ")3:9
Blower variable speed control with decorative wall
PLATE FOR ")3:9 6257
6257
4HERMO
DISK ONOFF BLOWER CONTROL FOR ")3:9 645 645
Blower to flexible pipe adaptor, BISAVF BISAVF
Backdraft damper, BISBD BISBD
Fireplace to Flex adaptor and 2 clamps, BISAF BISAF
Contact an IHP dealer to obtain any of these parts. Never use substitute
materials not approved by IHP. Use of non-approved parts can result
in poor performance and safety hazards.
* Available from Security Chimneys™
22
