Lennox Hearth Ladera-BN - Manual (Page 24)

Tubinox™ LL Chimney Lining System
Rigid Stainless Steel Liner For Relining A Masonry Chimney, 6” Diameter
Listed to ULC-S635M, UL-1777 and ULC-S640M at 2100º F
Description Cat./Part No.
6” Length, 6” Dia., 6LL6 6LL6
12” Length, 6” Dia., 6LL12 6LL12
24” Length, 6” Dia., 6LL24 6LL24
36” Length, 6” Dia., 6LL36 6LL36
48” Length, 6” Dia., 6LL48 6LL48
Adjustable Length (7” to 11”), 6” Dia., 6L7A 6L7A
Split Base Tee, 6” Dia., 6LT 6LT
Tee Cap, 6” Dia., 6TCS 6TCS
Twist Lock Tee Cap, 6” Dia., 6LTC 6LTC
Elbow 30º, 6” Dia., 6LE30 6LE30
Elbow 45º, 6” Dia., 6LE45 6LE45
Elbow 90º, 6” Dia., 6LE90 6LE90
Rain Termination Cap (regular), 6” Dia., 6LCS 6LCS
Rain Termination Cap (deluxe), 6” Dia., 6LCC 6LCC
Supports
Top Support, 6LST 6LST
Support Assembly, 6LSA 6LSA
Interior Support, 6LSB 6LSB
Adaptor Flexible Pipe (male), 6LAAM 6LAAM
Adaptor Flexible Pipe (female), 6LAAF 6LAAF
Stainless Steel Flex - five (5) feet Long, 6LLFLEX 6LLFLEX
Adjustable Insulated Wall Radiation Shield 6” - 12”, 6LRSMI 6LRSMI
Adaptors to Masonry Chimney
Masonry Chimney Adaptor, 45º, ")35-!
(for use with Tubinox liner) CANADA ONLY ")35-!
Masonry Chimney Adaptor, 30º, ")35-!
(for use with Tubinox liner) ")35-!
Gravity Kit Accessories
%LBOW Ž v DIA ":% ":%
%LBOW Ž v DIA ":% ":%
4ELESCOPIC LENGTH v DIA v TO v ":,! ":,!
!DJUSTABLE LENGTH v DIA v
v ":,! ":,!
7ALL RADIATION SHIELD v )$ ":2 ":2
"LACK GRILL WITH SUPPORT ":/ ":/
"RASS GRILL FOR ":+ ":'" ":'"
Length one (1) feet, 8KL1 8KL1
Length two (2) feet, 8KL2 8KL2
Length three (3) feet, 8KL3 8KL3
Length four (4) feet, 8KL4 8KL4
Length five (5) feet, 8KL5 8KL5
3%#52)49 #()-.%93Í
0!243 !.$ #/-0/.%.43 ,)343
The components listed below must be ordered from Security Chimneys International™. Contact your Security Chimneys Distributor or Dealer for ordering
information.
Security Chimneys International Limited
2125 Monterey, Laval, Quebec
Canada, H7L 3T6
www.securitychimneys.com 450-973-9999
53!
#ANADA
24
