NOTES:
M Nova Temp ® HT6000+ is equivalent to Secure Temp ® S-2100+
N Nova Temp HT6103+ is equivalent to Secure Temp ASHT+
O This appliance is equipped with the ASHT Chimney Adaptor. When other
chimney is used, a chimney adaptor for that chimney will be required.
P Chimney Adaptor (S-2100+ / HT6000+) for CANADA ONLY - If you want to
install a S-2100+ / HT6000+ chimney, an adaptor is available (6UCA).
Q AC Chimney is NOT recommended at elevations above 4,000 feet or in cold
climates (climates where temperatures will fall below 32° F / 0° C). When
using AC chimney, an AC6SB starter section must be used before installing
an elbow. When an offset is needed immediately off the top of the fireplace,
an elbow starter section, AC6SB30 (H3780), is available.
R Chimney Adaptor 7in - If you want to install a 7in ASHT / HT6103 chimney, an
adaptor is available (6AW7).
Secure Temp ® ASHT 1” High Temp. Insulated Stainless Steel Chimney
6” I.D. and 8” O.D., Double-Wall Stainl. Steel, Listed to CAN/UCL-S604 and UL-103HT
Description Part/Cat. No.
Lengths and Misc. Chimney Components
8” length, 6” Dia., 6L8 6L8
12” length, 6” Dia., 6L12 6L12
18” length, 6” Dia., 6L18 6L18
24” length, 6” Dia., 6L24 6L24
36” length, 6” Dia., 6L36 6L36
48” length, 6” Dia., 6L48 6L48
Adjustable Length 12”, 6” Dia., 6LA 6LA
15º elbow, 6” Dia., 6E15 6E15
30º elbow, 6” Dia., 6E30 6E30
Rain Termination Cap, 6” Dia., 6CC 6CC
Spark Arrester Screen (universal spark arrester band), PE PE
Wall Band, BM BM
Supports
Offset Support, SO SO
Roof Support, ST ST
Roof Brace, BS2 BS2
Firestops
Firestop, 6BF 6BF
Radiation Shield, 6RS 6RS
Insulated Attic Radiation Shield, 6RSA2 6RSA2
Insulated Wall Radiation Shield, 6RSM 6RSM
Insulated Wall Radiation Shield, 30º, 6RSMI30 6RSMI30
5NINSULATED 7ALL 2ADIATION 3HIELD Ž 23- 6RSM30
Attic Radiation Shield H0487
Roof Flashings
Flat Roof Flashing, 6FR 6FR
Ž
Ž &!2 6FAR
Ž
Ž &"2 6FBR
Storm Collar, 6FC 6FC
Chimney Adaptors
Chimney Adaptor, 6” (S2100, HT6000) 5#!
Chimney Adaptor, 6 to 7” (ASHT, HT6103) 6AW7
!# !IR
#OOLED #HIMNEY 3YSTEM
6” I.D. and 11” O.D. Air Cooled, Stainl. Steel inner and zinc coated steel exterior
* AC Chimney is NOT recommended at elevations above 4,000 feet or in cold climates
(climates where temperatures will fall below 32° F / 0° C).
Description Cat./Part No.
/NE OF THE FOLLOWING ADAPTORS IS REQUIRED
if installing an AC chimney system
Starter Section (adaptor), 6”, AC, AC6SB H3779
Starter 30º Elbow, 6” AC, AC6SB30 H3780
The following outside air kit is required if installing an AC chimney system
Chimney Outside Air Kit (flex, insulation, outside register
AND COUPLING !#:)
H1967
Lengths and Misc. Chimney Components
12” Length, 6” Dia., AC6L12 H0472
18” Length, 6” Dia., AC6L18 H0473
36” Length, 6” Dia., AC6L36 H0474
48” Length, 6” Dia. , AC6L48 H0475
15º Elbow, 6” Dia., AC6E15 H0476
30º Elbow, 6” Dia., AC6E30 H0477
Rain Termination Cap, 6” Dia., AC6CPR H0478
Spark Arrester Screen (universal spark arrester band), PE PE
Wall Band, XBM XBM
Supports
Offset Support, SO SO
Support Section, AC6SL H0481
Roof Support, ST ST
Roof Brace, BS2 BS2
Roof Flashings
Flat Roof Flashing, ACF H0494
Ž
Ž !# !DJ 2OOF &LASHING &! H0495
Ž
Ž !# !DJ 2OOF &LASHING &" H0496
Storm collar, ACFC H0500
Misc.
Telescopic attic radiation shield, ACRST H0498
Firestop, ACBF H0485
Radiation Shield, ACRS H0486
Attic Radiation Shield, ACRSA H0487
Insulated Wall Radiation Shield, 30º, ACRSMI30 H0489
23
3%#52)49 #()-.%93Í
0!243 !.$ #/-0/.%.43 ,)343
The components listed below must be ordered from Security Chimneys International™. Contact your Security Chimneys Distributor or Dealer for ordering
information.
Security Chimneys International Limited
2125 Monterey, Laval, Quebec
Canada, H7L 3T6
www.securitychimneys.com 450-973-9999
53!
#ANADA
