Comart
USB
1616-A
Specifies a USB attached DIO board. Enabling System Beep causes the speaker
located on the USB DIO to chirp on events such as triggered relays and
opened/closed alarm inputs.
ADAM
4052 /
4068
Adds an ADAM 4068/4052H COM port attached DIO device. Specify COM port
settings here.
ADAM
6060
Adds an ADAM 6060 network attached DIO device. Specify TCP/IP settings here.
Edit
Allows for changes to the configuration of the selected DIO device. Uses similar windows as the
Add function.
Delete
Removes the selected DIO device from the list.
Up
Moves the selected DIO device up the list and changes the numbering order of the inputs and
outputs.
Down
Moves the selected DIO device down the list and changes the numbering order of the inputs and
outputs.
