3xLogic Vigil System Server Software - User’s Guide Doc# 08100610 Page 79
Boundary
Orientation
These settings define the location of the boundary line. The boundary line is
displayed on the live image as a dashed line. If the centre point of a moving entity
crosses this boundary line, it will be counted as an in/out depending on the direction
of the crossing.
Reverse Count
Direction
Changes the way in/outs are counted by reversing the direction across the boundary
line.
Field Of View
Field Width/Height
The “Field Width” and “Field Height” settings define the physical size of the field of
view of the camera. This provides a reference point for the motion detection
algorithm to calculate the velocities of objects and distinguish multiple moving
bodies.
Show Live
Statistics
Specifies that the people counting overlays will be drawn on the camera view in the
Live Viewer. These overlays are not recorded with the footage.
Database Insert
Frequency
People counting tracks data for this period of time before writing to the database.
Information isn’t displayed in the People Counting window until the database has
been written to. Certain events will also cause immediate writing to the database,
such as closing the application or applying a settings change, even if elapsed time
hasn’t occurred.
Motion Sensitivity Specifies the motion detection sensitivity.
2.2 DVR Settings Tab
The DVR Settings tab contains settings related to the software and hardware configuration of Vigil Server.
