17
On-screen Display
• 8-channel: Choose from quad (CH1~4, CH5~8) or 9-way split (the bottom-right square appears
blacked out).
• 16-channel: Choose from quad (CH1~4, CH5~8, CH9-12, CH13~16), 9-way split (CH1~9,
CH10~2), or 16-way split (CH1~16).
Split-screen Selector (8-channel) Split-screen Selector (16-channel)
Flexible Camera Assignment (Swipe-to-Switch)
In Split-Screen view, you can re-assign your cameras to different positions. For example,
you can duplicate the video feed from channel 1 onto channel 2. This is useful if you wish
to obscure the number or location of your cameras.
NOTE: The DVR records cameras to their designated channels even if you reassign camera
positions.
Example: Channel 3 is reassigned to channel 5.
To re-assign camera positions using a mouse:
1 Select the channel you want to re-assign.
2 Click and hold the mouse.
• A camera menu appears.
3 While holding, move the mouse to the left
or right to change the camera. Release
the mouse button when the desired
camera is highlighted to select it.
