Appendix A: System Specifications
Appendix A: System Specifications
EDGE2 Series
SYSTEM
Operating System:
Linux (embedded)
Pentaplex:
Simultaneous View, Record, Playback, Backup & Remote
Configuration
Number of Channels:
8/16 Channel
Inputs/Outputs
Video In:
8/16 x 1Vp-p, CVBS, 75ohms, BNC
VGA Out:
VGA compatible
HDMI Out:
HDMI compatible
Audio In:
1 Line in(RCA)
Audio Out:
1 line out(RCA)
USB Port:
2 front & 1 back
PTZ Control:
RS485
Display
Live Display:
1 or 4 or 9 (8ch), 1 or 4 or 9 or 16 (16ch)
Live Display Speed:
240/480 (8/16ch NTSC)
200/400 (8/16ch PAL)
OSD:
ON/OFF
Activity Detection:
1200
Sensitivity Levels:
100
System Control:
USB Mouse, Front Panel Controls, Handheld Remote
Control, Touch Screen (Windows 7 touch compatible)
Firmware Upgrade:
Via USB device
User Authority:
ADMIN/USER1/USER2
Audio:
1-way audio conference (via network)
RECORDING
Video Compression:
H.264
Audio Compression:
PCM
Recording Speed & Resolution:
8/16
Channel
240 /200 @ 352x240 / 352x256 (NTSC / PAL)
120 /100 @ 704x240 / 704x256 (NTSC / PAL)
60 /50 @ 704x480 / 704x512 (NTSC / PAL)
Recording Resolution Setting:
Programmable per camera
Recording Quality Control:
5 levels
Image Size:
24 Kbyte (704x480), 12 Kbyte (704x240) 6 Kbyte
(352x240)
Recording Schedule:
By hour. by day, by recording mode, by Ch
Recording Modes:
Continuous, motion activated
Pre Recording:
Max. 10 seconds
Post Recording:
Max. 255 seconds
Reliability:
Watch-Dog, Auto-recovery after power failure
Covert Video:
Dynamic allocation of cameras
PLAYBACK
Playback Display:
1,4,9 (8ch), 1,4,9,16 (16ch)
Instant Playback:
for quick review of log events
Playback Speed:
Variable (1, 5, 15, 60)
Playback Player:
Apple QuickTime multi-hour Player
Backup Player:
Apple QuickTime multi-hour Player
Search: By
time,
event,
scroll
STORAGE & ARCHIVE
Storage:
Up to 1 HDD (SATA)
Maximum Capacity:
Up to 2TB
Backup Media:
USB Flash Drive (max 16GB)
Backup File Format:
MOV file (Codec included)
Bookmark Archiving:
Supported
CONNECTIVITY
Easy Connect:
Lorex Auto Port Forward Wizard
Software:
Edge Client Software for PC & Mac
Supported Operating
Windows™: 7, Vista, XP
Systems: Mac
Browsers:
Internet Explorer, Google Chrome (IE Tab) , Mozilla
FireFox
(IE
Tab)
Email Notification:
Text with weblink & snap shot attachment
Mobile Connectivity:
iPad™ , iPhone™ - 4.0 and above, Blackberry™ -
(supported model numbers: 9000, 9700, 9800),
Android
(version
2.1)
DDNS:
Free Lorex DDNS
Web Server Port:
Programmable by User
Network Protocol:
LAN, DHCP, Dynamic IP, DDNS
Network Interface:
10/100-Base-TX, RJ-45
Network Speed Control:
10 levels (28.8Kb ~ 1.5MB)/sec.
GENERAL
Power Consumption:
Approx. 30 watts
Supply Voltage:
100VAC-240VAC, 12VDC, 2.5A, 50/60Hz
Unit Dimensions
11.6” x 6.2” x 1.1”
(W x D x H):
295mm x 167.4mm x 34.0mm
Unit Weight:
3.2 lbs
Operating Temperature:
41° ~ 104° F / 5° ~ 40° C
Humidity:
10 ~ 75% NC
As our products are subject to continuous improvement, Lorex Technology Inc. and its
subsidiaries reserve the right to modify product design, specifications, and prices without
notice and without incurring any obligation.
E&OE
