Chapter
2.
Installing
optional
devices
This
chapter
provides
detailed
instructions
for
installing
optional
hardware
devices
in
the
server.
Server
components
The
following
illustration
shows
the
major
components
in
the
server
(depending
on
the
server
model).
The
illustrations
in
this
document
might
differ
slightly
from
your
hardware.
1
EMC
shields
12
Front
adapter-
support
bracket
2
Optical
drive
13
Hard
disk
drive
fan
assembly
3
Filler
panels
14
SAS/SATA
controller
4
Upper
bezel
15
Microprocessor
5
Lower
bezel
16
Heat
sink
6
SATA
filler
panel
17
Cover
7
SATA
hard
disk
drive
(some
models)
18
Hot-swap
power
supply
8
SAS
filler
panel
19
Non-hot-swap
power
supply
9
Hot-swap
hard
disk
drive
(some
models)
20
System
board
10
Diskette
drive
(optional)
21
DIMM
11
Drive
cage
22
Rear
system
fan
©
Lenovo
2008,
2009.
Portions
©
IBM
Corp.
2008.
13
