Appendices • MIDI Continuous Control Messaging (Part 2)
5 • 3
MIDI Continuous Control Messaging (Part 2)
Reverb Models: 0= Deluxe Spring, 1= Twin Spring, 2= King Spring, 3= Small Room 1, 4= Tiled Room 1,
5= Bright Room 1, 6= Dark Hall 1, 7= Medium Hall, 8= Really Large Hall, 9= Rich Chamber 1,
10= Rich Chamber 2, 11= Cavernous Chamber, 12= Slap Plate 1, 13= Plate, 14= Large Plate 1
A.I.R. II Models: 0=A.I.R. II Off, 1=Shure SM 57on axis, 2=Shure SM 57off axis, 3=MD 421 on axis,
4=MD4210 off axis, 5=U-67 on axis, 6= U-67 off axis
* = In addition to transmitting when a switch is stepped on, the state is stored with a Channel Memory and
transmitted when the Channel loads
Amp Parameter MIDI MIDI CC Range Notes
TX RX CC# Min Max
Reverb Enable
√
36 0 127 0~63=Off ; 64~127=On
Reverb Model
√
37 0 15 Range = 0~15, see list below
Reverb Decay
√
38 0 127
Reverb Pre-Delay
√
40 0 127 Non-Spring types
Reverb Tone
√
39 0 127
Split/Blend Mode
√
6 0 3 Range = 0~3. On prev. page
A.I.R. II Model
√
70 0 127 Range = 0~6. See list below.
FX Loop
√
107 0 127 0~63=Off ; 64~127=On
Tuner Enable
√
69 0 127 0~63=Off ; 64~127=On
Wah Enable
√ √
43 0 127 0~63=Off ; 64~127=On
Wah Position
√ √
4 0 127
Vol Pedal Position
√ √
7 0 127
Volume Pedal Minimum
Position
√
46 0 127
Volume PRE/POST
√
47 0 127 0~63 = Pre-Amp Model;
64~127 = Post-Amp Model
(FBV) Stomp Box 1
√
25 0 127 0~63=Off ; 64~127=On *
(FBV) Stomp Box 2
√
109 0 127 0~63=Off ; 64~127=On *
(FBV) Stomp Box 3
√
110 0 127 0~63=Off ; 64~127=On *
(FBV) Amp 1
√
111 0 127 0~63=Off ; 64~127=On
(FBV) Amp 2
√
112 0 127 0~63=Off ; 64~127=On
(FBV) Pitch/Tremolo
√
113 0 127 0~63=Off ; 64~127=On *
(FBV) Modulation
√
50 0 127 0~63=Off ; 64~127=On *
(FBV) Delay
√
28 0 127 0~63=Off ; 64~127=On *
(FBV) Reverb
√
36 0 127 0~63=Off ; 64~127=On *
(FBV) Tap
√
64 0 127 Momentary 127
