Appendices •
MIDI Continuous Control Messaging (Part 1)
5 •
2
MIDI Continuous Control Messaging (Part 1)
Amp Models: 0= Explorer, 1= Tweed 410, 2= Blackface, 3= Line 6 Clean, 4= Class A-30, 5= Plexi Lead, 6=
Brit 800, 7= Solo100, 8= Zen Master, 9= Small Tweed, 10= Blackface 212,11= Modern Class A, 12= Class
A-15, 13= Plexi 45, 14= Hiway 100, 15= Rectified
Cab Models: 0=Bypass, 1= 1X10 Gibson, 2= 4X10 Bassman, 3= 1X12 Deluxe, 4= 2X12 Line 6,
5= 2X12 Vox AC30, 6= 4X12 Marshall Greenback 25, 7= 4X12 Marshall V30, 8= 4X12 Soldano,
9= 2X12 Budda, 10= 1X12 Tweed, 11= 2X12 Twin, 12= 2X12 Matchless, 13= 1X12 VOX AC15, 14=
4x12 Marshall Greenback, 15= 4X12 Hiwatt, 16= 4X12 Mesa Boogie
Split/Blend Options (format = One Amp/Both Amps): 0=Blend/Blend; 1=Split/Blend; 2=Blend/Split; 3=Split/Split
Amp Parameter
MIDI
MIDI CC Range
Notes
TX
RX
CC#
Min
Max
Amp 1 Engage
√
√
111
0
127
0~63=Off ; 64~127=On
Amp 1 Model Select
√
0-7
√
12
0
15
Knob selects 0~7,
Range = 0~15. See list below.
Amp 1 Drive
√
√
13
0
127
Amp 1 Bass
√
√
14
0
127
Amp 1 Mid
√
√
15
0
127
Amp 1 Treble
√
√
16
0
127
Amp 1 Presence
√
√
21
0
127
Amp 1 Chan Volume
√
√
17
0
127
Amp 1 Split/Pan
√
√
10
0
127
Continuous (i.e. 0=left,
64=center, 127=right)
Amp 1 Reverb Send
√
√
18
0
127
Amp 1 Cabinet Model
√
71
0
16
Amp 1 Knob selects 1~8,
Range = 0~15. See list below
Amp 2 Engage
√
√
112
0
127
0~63=Off ; 64~127=On
Amp 2 Model Select
√
8-15
√
91
0
15
Knob selects 8~15,
Range = 0~15. See list below.
Amp 2 Drive
√
√
92
0
127
Amp 2 Bass
√
√
93
0
127
Amp 2 Mid
√
√
94
0
127
Amp 2 Treble
√
√
95
0
127
Amp 2 Presence
√
√
102
0
127
Amp 2 Chan Volume
√
√
103
0
127
Amp 2 Split/Pan
√
√
8
0
127
Same as Amp 1 Split/Pan
Amp 2 Reverb Send
√
√
106
0
127
Amp 2 Cabinet Model
√
104
0
16
Amp 2 Knob selects 9~16,
Range = 0~15. See list below.
