Working It Connecting External Speakers
2• 11
Hooking up your HD in side by side stereo with two 4x12s
Hooking up your HD in stacked stereo with two 4x12s
LEFT/
MONO
RIGHT
4 PER SIDE STEREO
OR
2 MONO (LEFT ONLY)
320 MAX WATTS TOTAL MONO 160 WATTS MAX PER SPEAKER
16 PER SIDE STEREO
OR
8 MONO (LEFT ONLY)
LEFT/
MONO
RIGHT
4 PER SIDE STEREO
OR
2 MONO (LEFT ONLY)
320 MAX WATTS TOTAL MONO 160 WATTS MAX PER SPEAKER
16 PER SIDE STEREO
OR
8 MONO (LEFT ONLY)
OUTPUT
IMPEDANCE
4 OHMS
CABINET
MODELING
OPEN 8 OHMS CLOSED OFF
RIGHT LEFT RIGHT
SPEAKER OUTS / CLASS 2 WIRING
LEFT
N222 N222
- MONO -
LEFT/
MONO RIGHT
4 PER SIDE STEREO
OR
2 MONO (LEFT ONLY)
320 MAX WATTS TOTAL MONO 160 WATTS MAX PER SPEAKER
16 PER SIDE STEREO
OR
8 MONO (LEFT ONLY)
LEFT/
MONO RIGHT
4 PER SIDE STEREO
OR
2 MONO (LEFT ONLY)
320 MAX WATTS TOTAL MONO 160 WATTS MAX PER SPEAKER
16 PER SIDE STEREO
OR
8 MONO (LEFT ONLY)
OUTPUT
IMPEDANCE
4 OHMS
CABINET
MODELING
OPEN 8 OHMS CLOSED OFF
RIGHT LEFT RIGHT
SPEAKER OUTS / CLASS 2 WIRING
LEFT
N222
N222
- MONO -
