NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE
7
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping
for leaks. Vacuum the control compartment, fireplace logs and
burner area.
Check Flame Patterns and Flame
Height Qualified Service Technician Refer to Figure 19 on Page 8 and verify the flame pattern
and height displayed by the appliance conforms to the picture.
Flames must not impinge on the logs.
Inspecting/Cleaning Pilot and Burner Qualified Service Technician Refer to Figure 19 on Page 8 and Figure 38 on Page 13.
Remove any surface build-up on pilot and burner assembly.
Wipe the pilot nozzles, igniter/flame rod and hood. Ensure the
pilot flame engulfs the flame sensor as shown.
Checking Vent System Qualified Service Technician Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation of the vent components.
Appliance Checkout Qualified Service Technician Perform the appropriate appliance checkout procedure detailed
in this manual.
Replacing Rockwool Ember Materials Homeowner/Qualified Service
Technician Remove old ember materials and vacuum the rockwool placement
area. Place new rockwool as described on Pages 11 & 12.
Periodically (After the Burning Season)
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior Homeowner Carefully remove logs, rockwool and and vermiculite. Vacuum out
interior of the firebox. Clean firebox walls and log grate. Replace
logs, Rockwool and vermiculite as detailed in this manual.
Check Flame Patterns and Flame
Height Homeowner Refer to Figure 19 on Page 8 and verify the flame pattern and
height displayed by the appliance conforms to the picture. Flames
must not impinge on the logs.
Checking Vent System Homeowner Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation of the vent components.
Cleaning Front Door Window Homeowner Clean as necessary following the directions provided in this
manual. DO NOT TOUCH OR ATTEMPT TO CLEAN GLASS WHILE
HOT.
Annually (Before the onset of the Burning Season)
MAINTENANCE SCHEDULE
