960L Owner’s Maunal MIDI
6-1
The MIDI implementation for the Rev 1 960L is very
basic. Since the implementation is fixed, there is no
user interface for modifying it.
Nomenclature
Numbering in MIDI, i.e. channel number, program
numbers, etc., can be confusing, since some sources
start counting from zero and others start from one. This
description will start from zero. If, for example, your
MIDI controller's lowest channel number is 1 (rather
than 0), you should add one to the values found in
channel table below.
MIDI Channel Allocation
The 960L uses a fixed channel allocation. All channels
are used or reserved, which means that 960L should
be the only device on its MIDI cable.
MIDI
Channel Usage Description
0 Global Channel Not currently in use
1 DSP Card Configuration of card.
2 Unused Reserved for Future Use
3 Unused Reserved for Future Use
4 Machine 1 Program change for machine 1
5 Machine 2 Program change for machine 2, if present in current configuration
6 Machine 3 Program change for machine 3, if present in current configuration
7 Machine 4 Program change for machine 4, if present in current configuration
8 Unused Reserved for Future Use
9 Unused Reserved for Future Use
10 Unused Reserved for Future Use
11 Unused Reserved for Future Use
12 Unused Reserved for Future Use
13 Unused Reserved for Future Use
14 Unused Reserved for Future Use
15 Unused Reserved for Future Use
