GUARDSMAN

GVB SERIES 2X2

Page 2 of 2

VANDAL RESISTANT, 2'x2' SURFACE BOX FLUORESCENT, 2 LAMP T8 OR 3 LAMP TT5

Lightolier

a Genlyte Thomas Company

www.lightolier.com

Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902

Section 6A/Folio P40-12

Job Information

Type:

OPTIONS & ACCESSORIES

FUSING:

Internal fast-blow fusing. SUFFIX: GLR.
Internal slow-blow fusing. SUFFIX: GMF.

RADIO INTERFERENCE FILTER: 120 or 277 volt, 50 or 60 Hz. One per fixture
standard. SUFFIX: RF.
ELECTRICAL/WIRING OPTIONS: Consult factory.

SPECIFICATIONS

MATERIALS: Chassis parts are die-formed 20 gauge cold rolled steel, stud
welded for rigidity. Lens Frame (FS) flush full-size steel frame.
FINISH: Chassis exterior—white baked acrylic enamel. Cavity—white
baked acrylic enamel minimum reflectance 86%. Phosphate undercoating.
LENS: (VL) prismatic lens is 3/16" thick, pattern 12, minimum impact strength,
130 foot pounds.
ELECTRICAL: Thermally protected class "P” ballast C.B.M. approved, non PCB.
If K.O. is within 3" of ballast, use wire suitable for at least 90°.
LABELS: I.B.E.W./UL and C-UL.

PHOTOMETRY

MODEL NO. GVB2SFSVL26U120SO

ORDERING INFORMATION

Explanation of Catalog Number. Example: GVB2SFSVL26U120SOGLR

GV

GUARDSMAN

VANDAL

RESISTANT :

B

BODY STYLE:

Surface Box

2

FIXTURE

WIDTH

S

CEILING

TYPE:

S=Surface

FS

LENS FRAME:

FS= Flat Full

Size Steel
Frame

VL

LENS/

SHIELDING

TYPE:

VL=High Impact

Prismatic
Lens
(Standard)

LAMP

QUANTITY:
(By Others)

2=2 Lamp
3=3 Lamp

(TT5

Lamp
Only)

LAMP/

FIXTURE
LENGTH:

6U = 6"U Lamp
2U = 1-5/8"U Lamp T8
FT = Twin Tube T5

VOLTAGE:

120 or 277

OPTIONS:

Add appropriate suffix

to catalog no., ie: (GLR)

coefficients of utilization — zonal cavity method
