Linksys Ethernet SGE2010 - Manual (Page 40)

SGE2010/SGE2010P Administration Guide 37
System Configuration
Using the Console
Ping IPv6
You can use the Ping IPv6 screen to ping an IPv6 address.
To open the screen:
1. From the Switch Main Menu, select 1. System Configuration.
2. From the System Configuration Menu, select 6. IP Configuration.
3. From the IP Configuration menu, select 5. Network Configuration.
4. From the Network Configuration menu, select 2. IPv6 Ping.
To change the IP address:
1. Select Edit, and then enter the IPv6 address.
2. Press the Esc key to move the cursor to the Action list.
3. Select Save to save your changes.
4. When the Operation complete message appears, press the Esc key to move the cursor to the
Action list.
To begin the ping test:
1. Select Execute to begin the ping test.
2. After the ping test is complete, the results of the test appear on the screen.
3. When the Operation complete message appears, press the Esc key to move the cursor to the
Action list.
