Mj series, Hicago, Ecessed – Lightolier Chicago Gimbal Unit MJ User Manual
Page 2: Imbal
MJ Series
C
HICAGO
R
ECESSED
G
IMBAL
U
NIT
Page 2 of 2
Philips Lightolier
e: [email protected]
t: (508)
679-8131
w: www.lightolier.com
MJ Series September 19, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011. All rights reserved.
Job Information
Type:
Ordering Information
Series
MJ = Chicago
Gimbal Unit
MJ
12 = 12 W
Battery Wattage
1 = 6 V
Voltage
W = White
Housing Color
Quick Connect for
Lamp Assembly
Plaster Ring
(supplied)
Gimbal Ring
(PAR 36 lamp)
AC Ready Light
Electronics and Battery
Compartment
Test Switch
Torsion Spring
Trim Retainer
Trim Ring Diameter
8.5" (21.6 cm)
1
12
W
B = Black Finish
SP = Special Paint Finish - Specify Color
Factory Installed Options
UNIT
MJ112W
DC
VOLTAGE
6
LAMP
WATTAGE
12
BATTERY WATTS TO 87 1/2
OF RATED VOLTAGE*
1 1/2 HRS
12
Unit Battery Capacity
2 HRS
8
* Per NEC specifications.
AC Junction
Box
