PIPELINER 8P+
AWS: E8010-P1 Cellulosic All Position Stick (SMAW) Electrode
Here’s an electrode that makes
short work of even the most
challenging high silicon pipe
applications! Pipeliner 8P+ is an
outstanding choice for API 5L-X56
through X70 grade pipe. This elec-
trode features high stacking efficiency
– formulated to carry and deposit weld
metal in difficult vertical down out-of-
position applications.
ADVANTAGE LINCOLN
• Manufactured to metric electrode
diameters – use anywhere in the
world.
• Fill and Cap Consistency – Approved
manufacturing sites deliver industry-
leading consistency in composition
and arc action.
• Excellent Resistance to Porosity –
Repeated x-ray testing shows out-
standing results.
• High Stacking Efficiency –
Formulated to carry and deposit
weld metal in difficult vertical down
out-of-position applications. Fill
joints in fewer passes.
• Exceptional mechanical properties –
Consistent best-in-class perfor-
mance.
• Manufactured to actual lot control.
Actual certificates of conformance
are available upon request.
TYPICAL APPLICATIONS
• Typical applications include high-
yield pipe steels.
WELDING POSITIONS
CONFORMANCE
AWS A5.5: E8010-P1
ASME SFA-5.5: E8010-P1
ABS: E8010-P1
CSA W48-01: E55010-P1
EN499: E 46 4 1Ni C 25
Charpy V-Notch
Yield Strength Tensile Strength Elongation ft.-lbs. (Joules)
psi (MPa) psi (MPa) (%) @ -20ºF (-29ºC) @ -50°F (-46°C)
Required
AWS E8010-P1
67,000 (460) 80,000 (550) 19 20 (27) Not .
min. min. min. min. Required
Typical Results
As-welded
67,000-81,000 80,000-98,000 19-27 46-73 34-62 .
(460-559) (550-676) (62-99) (46-84) .
%C %Mn %Si %Ni %Cr %Mo %V %S %P
Requirements
.20
1.20 .60 1.00 0.30 .50 0.10 0.03 0.03
AWS E8010-P1 max. max. max. max. max. max. max. max. max.
Typical Results .15 -.19 .60 -.85 .15 -.32 .67 -.85 .01 -.04 .15 -.30 < .01 .005 -.010 .008 -.015
DEPOSIT COMPOSITION - As Required per AWS A5.5-96
MECHANICAL PROPERTIES - As Required per AWS A5.5-96
Manufactured in metric diameters, U.S. Customary sizes are approximate.
3G
➔
3G ➔
5G ➔ 5G
➔
1G 2F 2G
4G
DIAMETERS / PACKAGING
NOTE: Pipeliner electrodes
are manufactured under lot
control. A Certificate of Test
showing actual deposit
chemistry and mechanical
properties per AWS A5.5
(DC+ only) is available on
request from the factory for
every lot of electrode.
(Fax 216-383-8386).
TYPICAL OPERATING PROCEDURES
Current (Amps)
Polarity
3.2mm 4.0mm 5.0mm
(1/8") (5/32") (3/16")
DC+ 75 - 130 100 - 185 140 - 225
4.5 kg (10 Lb.)
22.7 kg (50 Lb.)
Diameter Easy Open Cans
Easy Open Cans
mm (in.) [ 27.2 kg (60 lb.) Master ]
3.2 (1/8) ED030829 ED030826
4.0 (5/32) ED030830 ED030827
5.0 (3/16) ED030831 ED030828
NOTE: This AWS electrode
classification is not required
to deposit weld metal that
is low in diffusible hydrogen.
Therefore, these electrodes
should not be used in
applications where the
hydrogen content of the
weld metal is required to
be controlled.
