8
Pipeliner
www.lincolnelectric.com
PIPELINER 6P+
AWS: E6010 Cellulosic All-Position Stick (SMAW) Electrode
DIAMETERS / PACKAGING
Charpy V-Notch
Yield Strength Tensile Strength Elongation ft•lbf (Joules)
psi (MPa) psi (MPa) (%) @ -20ºF (-29ºC)
Required 48,000 (330) 60,000 (410) 22 20 (27)
AWS E6010 (as-welded) min. min. min. min.
Typical Results
As-welded
57,000 - 76,000 72,900 - 86,200
24 - 33
38 - 63
(393 - 524) (503 - 594) (51 - 85)
Stress-relieved (1) 51,000 - 64,000 67,000 - 78,000
30 - 34
45 - 53
1 hr @ 1150°F (612°C) (352 - 579) (462 - 538) (61 - 72)
%C %Mn %Si %S %P
Requirements
AWS E6010
Not Specified
Typical Results .10-.20 .40-.65 .11-.30 .009-.020 .005-.025
Pipeliner 6P+ is an all-position
cellulosic pipe electrode designed
especially for vertical down root
pass welding. This electrode is based
on a long-time favorite among cross-
country pipeline welders.
ADVANTAGE LINCOLN
• All-position; particularly good for
vertical and overhead.
• Light slag with little slag interference
for easy arc control. Easy slag
removal, smooth bead.
• Deep penetration with maximum
dilution.
• Capable of x-ray quality welds,
even out-of-position.
DEPOSIT COMPOSITION
- As Required per AWS A5.1-91
• Manufactured under a quality
system certified to ISO 9001
requirements.
• Manufactured to actual lot control.
Actual certificates of conformance
are available upon request.
TYPICAL APPLICATIONS
• Designed especially for all-position
vertical down root pass welding.
MECHANICAL PROPERTIES - As Required per AWS A5.1-91
WELDING POSITIONS
3G
➔
3G ➔
5G ➔ 5G
➔
1G 2F 2G
4G
(1) Data provided for information only – not part of AWS classification.
NOTE: Pipeliner electrodes
are manufactured under
lot control. A Certificate
of Test showing actual
deposit chemistry and
mechanical properties
per AWS A5.1 (DC+ only)
is available on request
from the factory for every
lot of electrode.
(Fax 216-383-8386).
CONFORMANCE
AWS A5.1: E6010
ASME SFA-5.1: E6010
CSA W48.01: E41010
EN499: E 42 3 C 25
TYPICAL OPERATING
PROCEDURES
Current (Amps)
Polarity
1/8” 5/32” 3/16”
(3.2mm) (4.0mm) (4.8mm)
DC+ 65 - 130 90 - 175 140 - 225
NOTE: This AWS electrode classification is not
required to deposit weld metal that is low in diffusible
hydrogen. Therefore, these electrodes should not be
used in applications where the hydrogen content of the
weld metal is required to be controlled.
Diameter 10 Lb. (4.5 kg)
50 Lb. (22.7 kg)
in. (mm) Easy Open Cans
Easy Open Cans
[ 60 lb. (27.2 kg) Master ]
1/8 (3.2) ED030845 ED030848
5/32 (4.0) ED030846 ED030849
3/16 (4.8) ED030847 ED030850
Manufactured in metric diameters, U.S. Customary sizes are approximate.
