EXPLANATION OF THE MIB
FOR RMS
Structure of the MIB
Key to the following Tables:
INT Integer
CNT Counter
DS Display
String
OS Octet String
TT TimeTicks
RO Read
Only
RW Read Write
Objects under RMS system
(1.3.6.1.4.1.1909.10.1)
for example
Reset RMS
1.3.6.1.4.1.1909.10.1.4.0 := 1
The RMS can be accessed under the OID 1.3.6.1.4.1.1909.
(iso.org.dod.internet.private.enterprises.infratec.rms)
rms
1 rmssystem
2 input
1 digitalInTable
2 alertInTable
3 upsInTable
3 output
1 outputTable
2 outputLogicTable
4 temp
1 tempTable
5 humid
1 humidTable
6 mains
1 mainsTable
7 filter
1 filterTable
2 filterDigitalInTable
3 filterAlertInTable
4 filterUPSINTable
5 filterTempTable
6 filterHumidityTable
7 filterMainsTable
8 filterFeedbackTable
8 message
1 messageTable
9 user
1 userTable
20 aux
21 icc
Variable Type Value Access
1 systemVersion DS RO
2 systemSNMPsave INT { default (1), RW
save (2) }
3 systemMsgToSyslog INT { msglog-off (1) RO
msglog-on (2) }
4 systemReset INT { default (1), RW
reset (2) }
5 systemSNMPaccess INT { readonly (1), RO
readwrite (2) }
10
10
The complete MIB in ASN.1-
Notation is on the enclosed
CDROM as the file “RMS MIB”
