ACCESSORIES
C-8 C-8
LN-9 Wire Feeder Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Master TOC
Retur
n to Master TOC
Retur
n to Master TOC
Retur
n to Master TOC
TABLE C.2 – DRIVE ROLL AND GUIDE TUBE KITS
Wire Size
Kit
2-Roll 4-Roll
Solid Steel Electrode
.030 - .035” (0.8 - 0.9 mm) KP502 - 035 KP545 - 035
.045 - 0.052” (1.2 - 1.4 mm) KP502 - 052 KP545 - 052
1/16” (1.6 mm) KP502 - 1/16 KP545 - 1/16
.068 - 3/32” (1.7 - 2.4 mm) KP502 - 3/32 KP545 - 3/32
Cored Electrode
.045 - 0.052” (1.2 - 1.4 mm) KP502 - 052C KP545 - 052C
1/16” (.062”) (1.6 mm) KP502 - 1/16C KP545 - 1/16
.068 - 3/32” (1.7 - 2.4 mm) KP502 - 3/32 KP545 - 3/32
7/64 - .120” (2.0 - 3.0 mm) KP502 - 120 KP545 - 120
7/64” Soft Jacket (2.8 mm) KP502 - 7/64H __________
Aluminum Electrode
.035” (0.9 - 1.0 mm) KP503 - 035A KP546 - 035A
3/64” (1.2 mm) KP503 - 3/64A KP546 - 3/64A
1/16” (1.6 mm) KP503 - 1/16A KP546 - 1/16A
