Menu Groups
40
Using printer menus
NetWare
Use these menu items to view or change the printer NetWare settings.
Baud Specifies the rate at which data can
be received through the serial port.
Note: 138200, 172800, 230400,
and 345600 baud rates are
displayed in the Standard Serial
menu. These values are not
displayed in the Serial Option 1,
Serial Option 2, or Serial Option 3
menus.
1200
2400
4800
*9600
19200
38400
57600
115200
138200
172800
230400
345600
Data Bits Specifies the number of data bits
that are sent in each transmission
frame. 7
*8
Parity Sets the parity for serial input and
output data frames. Even
Odd
*None
Ignore
Honor DSR Determines whether the printer
uses the Data Set Ready (DSR)
signal. DSR is one of the
handshaking signals for most serial
interface cables.
The serial interface uses DSR to
distinguish data sent by the
computer from data created by
electrical noise in the serial cable.
This electrical noise can cause stray
characters to print. Select On to
prevent stray characters from
printing.
*Off All data received by the serial port is
treated as valid data.
On Only data received while the DSR
signal is high is treated as valid.
Menu item Purpose Values
View Login
Name Displays the assigned NetWare
login name. Selecting View Login Name displays the NetWare name on
the operator panel.
View Print Mode Displays the assigned NetWare
print mode. Selecting View Print Mode displays the NetWare print mode
on the operator panel.
View Network
Number Displays the assigned NetWare
number. Selecting View Network Number displays the NetWare
network number on the operator panel.
Menu item Purpose Values
