37
To configure IP details from a global user location
1 Use either the VNC viewer or a standard web browser to make remote
for more details.
2 If the username entry is not blanked out, enter ‘admin’. Then enter the
admin password (if no password is set, then just press
). Once logged
in, the MC5-IP will show the video output from the host system (if one is
connected), or otherwise a ‘No Signal’ message.
3 Click the Configure button in the top right hand corner of the window to
display the main configuration page
ò
Allows you to create and manage up to sixteen separate user
accounts, each with separate access permissions.
Allows you to alter both basic and fundamental
settings within the MC5-IP.
Allows you to configure all aspects relating to time keeping
within the MC5-IP unit.
Here you can alter any of the existing network settings plus you
can take advantage of the IP access control feature that lets you
to specifically include or exclude certain addresses or networks.
Lets you setup or alter the details concerning
the modem and power control serial ports.
Allows you to configure user access, hot key switching and
power control codes for up to 128 host systems that may be
connected to the MC5-IP via other cascaded units.
Provides various details about the user
activity on the MC5-IP.
For more information about each page, please see
Configuration pages via viewer
in the ‘Further information’ chapter.
Shaded items signify
options that are not
available via the standard
configuration menus.
IP configuration by global user
Once the basic IP-related features have been configured using the MC5-IP
configuration menus, further changes can be made by authorised global users
via the VNC interface. There are two main ways to use the VNC interface to
access the MC5-IP unit:
•
– a small application supplied on the CD-ROM or
downloadable from the RealVNC website or even downloadable from the
MC5-IP itself.
or
•
A standard browser that supports Java
– When a web browser makes
contact, the MC5-IP provides the option to download a Java application to
it. This allows a viewer window to be opened and operation to commence
just as it would with the VNC viewer application.
