Impinger I -–1000 Series Service Manual - International
94
PARTS / 1033, 1034, 1046, 1047
LETTER
P/N
DESCRIPTION
A
369247
Shaft Lock Ring
B 369248
Knob
C 357107
Fuse
Holder
D
369013
Fuse, 3 Amp
369014
Fuse, 10 Amp
E
369603
Motor, Gear Box Assy.
F
369066
Sprocket, 10 Tooth
G 369260
On/Off
H 350224
Lens,
Yellow
J 369572
Burner
Light
K 369507
Cooling
Fan
Thermostat
L 369422
Relay,
240V
M 369253
Relay,
120V
N
369605
Transformer, Stepper Control
O
369508
Timer, 20 Minute
P 369640
Control,
Stepper
Q 369173
Transformer,
Control
R 369543
Transformer,
Power
S 369368
Thermostat,
Hi-Limit
T 369331
Finger
Guard
U 369579
Alarm
V 369574
Spark
Generator
W 369573
Ignition
Control
369771
Push
Button
Switch
X
369580
Gas Valve (Multi Block)
Y
369571
Connector, 4- Pole
Z
369570
Connector, 3- Pole
AA
369398
Solenoid Valve, Nat & LP Gas
BB 369193
Thermistor
Probe
DD 369172
Time/Temp
Display
EE 369801
Temperature
Control
FF 369131
Thermocouple
GG
369072
Main Burner Orifice, Nat. Gas
369099
Main Burner Orifice, LP Gas
HH
369144
Pilot Shield, Extension
JJ
369202
Pilot Shield, Main
KK 369075
Flame
Sensor
LL
369073
Pilot Orifice, Nat. Gas
369100
Pilot Orifice, LP Gas
MM 369076
Burner
Igniter
NN 369142
Flame
Target
OO
369589
Burner Blower Motor
PP 369736
Magnet
QQ 369737
Sensor,
Hall
Effect
RR
369575
Differential Air Pressure Switch
SS 369124
Cooling
Fan
TT 369391
Potentiometer,
Conveyor
UU
369898
Flame Monitor, 1033/ 1034
