Impinger I -–1000 Series Service Manual - International 88
PARTS / 1028-1029-1032
LETTER P/N DESCRIPTION
A 369247 Shaft Lock Ring
B 357107 Fuseholder
C 369014 Fuse, 10 Amp
369335 Fuse MDL Time Delay, 1 Amp
369195 Fuse, 1 Amp FNM1
369304 Fuseholder for FNM1 Fuse
369013 Fuse, 3 Amp
D 369248 Knob
369064 Conveyor Speed Control Dial (Non-digital Display Ovens)
E 369066 Sprocket, Drive - S/N 4389 & Below and Q19078 & Above
369158 10 Tooth Sprocket - S/N 4390 to Q19077
F 369260 Switch, ON/OFF
G 369605 Transformer (Stepper)
H 350224 Lens, Yellow
I 369128 Neon Pilot Light, 125 VAC
J 369025 Blower Air Switch
K 369022 Motor,Conveyor S/N 4389 & Down See Pg 104 S/N 4390 & Up
369113 Brush (For 369022)
369114 Brush Cap (For 369022)
369115 Brush Spring (For 369022)
L 369302 Contactor, 50A, 120V
M 354258 Transformer, 230V-115V
N 369127 Hi Limit Thermostat
369368 Hi Limit Thermostat--Bulb & Capillary
O 369154 0.7 Amp Circuit Breaker
P 369118 Power Terminal Block
Q 369007 Temperature Sensing Switch
369902 Sensing Rod Kit
R 369119 60A Fuseholder
S 369134 Fuse, 50A
T 369155 Conveyor Motor Control Board S/N 4390-Q19077
369008 Conveyor DC Control Board - S/N 4389 & Below
369640 Control Stepper, S/N Q19078 & Above
357028 Fuse, Non Delay, 1A 250V
369201 Fuse, 4 Amp, 250V
U 369240 Hi Hat
V 369193 Thermistor Probe
W 369167 Set Switch Assy.
370046 Button Only
X 369172 Digital Display
Not Shown 369029 Temperature Gauge (Non-digital Display Ovens)
Uses 369009 Thermocouple
Y 369342 Knob, Temperature Control
Z 369340 Potentiometer, Temp. Control & Harness
A A 369132 Temperature Control Board
B B 369173 Control Transformer
C C 369131 Thermocouple Probe Assy.
D D 369032 Relay
E E 369124 Cooling Fan, Control Box
