Impinger I -–1000 Series Service Manual - International 106
PARTS / SERIES 1000 – CONVEYOR
LETTER P/N DESCRIPTION
A 369002 Tension Knob, Conveyor
B 369314 Roll, Conveyor-Notched
C 369835 Conveyor Frame Assy.
D 369312 Conveyor Shaft, Idler
E 369160 Conveyor Pan Stop
F 369641 Idle Bearing Bracket
G 369220 Idle Bearing
H 369005 Conveyor Belt Connecting Link
I 369237 Conveyor Drive Shaft
J 369161 Roller Chain Sprocket, S/N 2164-Q14973 (Gas)
S/N 2164-Q19077 (Electric)
369066 Drive Sprocket S/N Q14974 & Above (Gas)
S/N Q19078 & above (Electric)
369413 Drive Key
K 369219 Rod End, Female
L 369644 Screw 1/2-20 x 3/4
M 369206 Crumb Pan
N 369163 Conveyor Belt
369362 Conveyor Belt by Foot
O 369143 Crumb Pan
P 369036 Drive Bearing Assy.
Q N.L.A. Conveyor Frame
(Replace with 369117 Complete Conveyor Assy.)
R 369380 Conveyor Guard Strap
S 369060 L.H. Conveyor Guard Assy.
T 369037 Snap Ring
U 369034 L.H. Conveyor Idler Bearing Assy.
V 369035 R.H. Conveyor Idler Bearing Assy.
W 369042 Idler Shaft
X 369039 Blank Drive Gear
Y 369038 Notched Drive Gear
Z 369043 Drive Shaft
A A 369059 R.H. Conveyor Guard Assy.
B B 369040 Conveyor Sprocket (Uses 369042 Key
