Impinger I -–1000 Series Service Manual - International 84
PARTS / MODEL 1002-1003, S/N 4390 & UP
LETTER P/N DESCRIPTION
A 369247 Shaft Lock Ring
B 357107 Fuse Holder
369012 Fuse Holder
C 369013 Fuse, 3 Amp
369014 Fuse, 10 Amp
D 369064 Conveyor Speed Control Dial (Non-Digital Display Ovens)
369248 Knob
E 369158 10 Tooth Sprocket - S/N 4390 & Above
F 350705 Switch, ON/OFF
G 369260 Double Pole Fan Switch
H 350224 Lens, Yellow
I 369104 Pilot Light, 24 VAC
J 369507 Cooling Fan Thermostat
K SEE PAGE 104
L 369025 Blower Air Switch
M 369032 Relay
N 369155 Conveyor Motor Control Board
357028 Fuse, Non Delay, 1A 250V
369201 Fuse, 4 Amp, 250V
O 369240 Hi Hat
P 369007 Temperature Sensing Switch
Q 369173 Control Transformer
R 369363 Unit Relay Cover, Top LH
S 369543 Transformer, 230/460/575
T N. L. A See Burner Blower Motor - Page 55
U 369531 Transformer, 120/24V - 40VA
V 369366 Burner Blower Motor Kit
W 369331 Finger Guard, Cooling Fan
X 369193 Thermistor Probe
Y 369167 Set Switch Assy.
Z 369172 Digital Display
369029 Temperature Gauge
AA 369108 Thermostat Knob (Degree F)
369300 Thermostat Knob (Degree C)
B B 369263 Gas Valve (Body Only), NAT/LP
369393 Ignition Control, NAT & LP
C C 369344 Pilot Shut Off Valve
D D 369006 Temperature Control Valve
E E 369072 Main Burner Orifice, Natural Gas
369099 Main Burner Orifice, LP
F F 369144 Pilot Shield, Extension
G G 369202 Pilot Shield, Main
H H 369075 Flame Sensor
I I 369073 Pilot Orifice, Natural Gas
369100 Pilot Orifice, LP
JJ 369076 Burner Ignitor
K K 369142 Flame Target
L L 369154 0.7 Amp Circuit Breaker
MM 369124 Cooling Fan, Control Box
369535 Cord Set, Cooling Fan
N N 369067 Air Switch Tube
O O 369152 Oven Conveyor Control Pot.
