Communication Interfaces
77
12.1.1 Connecting and Using a Terminal
An RS-232 connection can be used to connect the STS2 to either a terminal or a PC running terminal
emulation software. If you are unsure of the cable pin out, see 15.2.10 - Terminal Port Connec-
tions.
1. Connect the terminal to the STS2 by plugging the cable from the terminal into the RS-232 port.
This connection can be made at any time.
2. After making the connection, verify the communications link by pressing
terminal keyboard.
The interface communications system responds as indicated below:
The SVTP-Control > prompt indicates that RS-232 communications are established.
• If you receive no response or prompt, verify that the connector is properly plugged into the
port and the PC or terminal serial interface is working properly.
3. Enter the desired commands, as listed in Table 10.
For additional help type > <command> or
Refer to the corresponding menu options in the 13.0 - STS2 Touch Screen Display for more details
about the commands.
Some terminal commands require a password to function. Use the PWD command and a valid pass-
word to gain access.
Table 10
Terminal Commands
Keys
Function
?
Displays this help menu or specific help with a command
AA?
Displays active alarms
AF?
Displays active faults
CEL
Clears the event log
CHL
Clears the history logs
DATE?
Displays current system date
DATE
Sets system date
EL?
Displays the entire event log
HELP?
Displays this help menu or specific help with a command
HLn?
Displays the history log #n, if frozen
LOGOUT
Logs user out of unprotected mode
PS?
Displays the preferred source
PS n
Sets the preferred source to #n
PWD
Allows users to access protected commands
QUIT
Modem only. Ends the session and hangs up the modem.
SH
Silences the horn
SPT? Displays
all
current setpoints
SPTx
Displays current setpoints for group x. See 12.1.2 - Configuring the STS2 via the
Terminal for a description of groups.
SR? Displays
status
reports
TIME?
Displays current system time
TIME
Sets system time
UPMDR? Displays
metering
data
VER?
Displays firmware versions
Repeating command -->
Illegal command!
> or
>
SVTP-Control >
