Reattaching the Faceplate:

Hold the faceplate so that the control panel faces the front
toward you and set the left side of the faceplate in the
faceplate bracket.

Do not set the right side of the faceplate in the faceplate bracket
first, when reattaching the faceplate. Doing so may cause the
connector on the faceplate bracket to malfunction.

Press the right side of the faceplate until it locks.

If the faceplate bracket's angle was not set to the vertical when
the faceplate was mounted, check that the faceplate is securely
attached to the faceplate bracket by holding its right side and
pulling it gently towards you.

NOTE

2CAUTION

Holding the center part of the faceplate, pull it out.
The faceplate bracket will automatically close.

• When removing the faceplate, pull it out only when it is fully

open. The detachment of the faceplate while it is moving might
result in damage to the unit.

• Do not apply excessive force to the faceplate bracket without

attaching the faceplate. Doing so will cause the faceplate
bracket to be deformed.

• Do not touch the connector on the faceplate bracket after

removing the faceplate. Touching the connector may cause
damage to the unit.

• Do not touch two metal parts on both sides of the faceplate

bracket. Touching those parts may injure you.

• Sliding the faceplate lock switch cause the unit’s power to turn

off. If you want to operate the unit again, remove the faceplate
from the faceplate bracket completely and then reattach it.

• The faceplate is a precision piece of equipment and can be

damaged by shocks or jolts. For that reason, keep the faceplate
in its special storage case while detached.

• Do not expose the faceplate or its storage case to direct

sunlight or excessive heat or humidity. Also avoid places with
too much dust or the possibility of water splashing.

NOTE

2CAUTION

Faceplate lock switch
