English 13 12 English
Specifications
Specifications subject to change without notice.
Audio Section
Max Power Output (4 Ω )
4 Channel Mode ........................................................................................................150 W × 4
3 Channel Mode ..................................................................................150 W × 2 + 600 W × 1
2 Channel Mode ........................................................................................................600 W × 2
Rated Power Output (4 Ω ) (+B = 12.0 V)
4 Channel Mode ..................................................................50 W × 4 (DIN45324, +B=12.0 V)
3 Channel Mode ..................50 W × 2 (1 kHz, 0.05 % THD) + 200 W × 1 (1 kHz, 0.5 % THD)
2 Channel Mode........................................................................200 W × 2 (1 kHz, 0.5 % THD)
Rated Power Output (2 Ω ) (+B = 12.0 V)
4 Channel Mode........................................................................100 W × 4 (1 kHz, 0.5 % THD)
Rated Power Output (4 Ω ) (+B = 14.4 V)
4 Channel Mode ..................................................................75 W × 4 (DIN45324, +B=14.4 V)
3 Channel Mode ..................75 W × 2 (1 kHz, 0.05 % THD) + 300 W × 1 (1 kHz, 0.5 % THD)
2 Channel Mode........................................................................300 W × 2 (1 kHz, 0.5 % THD)
Rated Power Output (2 Ω ) (+B = 14.4 V)
4 Channel Mode........................................................................150 W × 4 (1 kHz, 0.5 % THD)
Frequency Response (+0, –1 dB) ............................................................................5 Hz ~ 50 kHz
Total Harmonic Distortion (Rated power)
# ............................................................0.010 % (1 kHz)
Signal to Noise Ratio............................................................................................................110 dB
Sensitivity (rated output) (MAX) ..............................................................................................0.2 V
Sensitivity (rated output) (MIN) ..............................................................................................5.0 V
Input Impedance....................................................................................................................10 k Ω
Damping Factor..............................................................................More than 1000 (at ∑ connect)
Low Pass Filter Frequency (24 dB/oct.) (Variable) ......................................................50 ~ 200 Hz
High Pass Filter Frequency (12 dB/oct.) (Variable) ......................................................50 ~ 200 Hz
Infrasonic Filter Frequency (24 dB/oct.) ..........................................................................15 / 25 Hz
# Sensitivity = Mini. , Through LPF (30 kHz)
General
Operating Voltage ..............................................................................12.0 V (11 ~ 16 V allowable)
Current Consumption (4
Ω , +B = 12.0 V, 10% THD) ..............................................................42 A
Dimensions (W × H × D) ................................................................................272 Ч 58 Ч 450 mm
Weight ..................................................................................................................................7.0 kg
Troubleshooting guide
Often, what appears to be a malfunction is due to user error. Before
calling for service, please consult the following table.
Symptom Cause Remedy
No sound.
(No sound from one side.)
The output level is too
small (or too large).
The sound quality is bad.
(The sound is distorted.)
• Input (or output) cables are
disconnected.
• The connection of the sigma
servo terminals is wrong.
• Protection circuit may be
activated.
• The fuse may be blown
because the volume was too
high.
The input sensitivity adjusting
control is not set to the correct
position.
• The speakers cable are
connected with wrong + / -
polarity.
• A speaker cable is pinched by a
screw in the car body.
• The switches may be set
improperly.
• Connect the input (or output)
cables.
• Check the connection referring
to "Sigma servo feedback".
• Check connections by referring
to "Power indicator".
• Replace the fuse with a new
fuse and use a lower volume.
Adjust the control correctly
referring to “Controls”.
• Connect them properly checking
the + / - of the terminals and
cables well.
• Connect the speaker cable again
so that it is not pinched by
anything.
• Set switches properly by
referring to "Controls" and
"System examples".
