Specifications
Specifications subject to change without notice.
Monitor Unit
Screen size ..................................................................................................................8.0 inches wide
176.4(W) x 99.2(H) x 202(Diagonal) mm
6-15/16(W) x 3-7/8(H) inch
Display system ............................................................................................Transparent TN LCD panel
Drive system ..................................................................................................TFT active matrix system
Number of pixels ........................................................................336.960 pixels (480 H x 234 V x RGB)
Effective pixels..........................................................................................................................99.99%
Pixel arrangement..........................................................................................RGB striped arrangement
Back lighting ............................................................................................................Cold cathode tube
Phone jack (Miniplug x 1) Audio output level........................................Stereo Mini Jack / 820 mV/32 Ω
Built-in speaker ..........................................................................................................1W (40 x 20 mm)
Video Box Unit
Color system ....................................................................................................NTSC/PAL(Compatible)
Video input level (RCA jack) ..............................................................................................1 Vp-p/75 Ω
Audio input level (RCA jack) ..................................................................................................1 V/22 KΩ
Video output level (RCA jack) ..............................................................................................1 Vp-p/75 Ω
Audio output level (RCA jack)............................................................................................500 mV/1 KΩ
RGB Input (13 Pin) ..........................................................................................................0.7 Vp-p/75 Ω
General
Operating voltage ..............................................................................................14.4 V DC (11 to 16 V)
Consumed Power ......................................................................27 W (25 W:during normal operations)
Operational temperature range ....................................................................................–10°C to +60°C
Storage temperature range ..........................................................................................–30°C to +85°C
Size
(Monitor unit) ........................................................................................211.3(W) x 134(H) x 30(D) mm
8-5/16(W) x 5-1/4 (H) x 1-3/16(D) inch
(Video box unit) ......................................................................................188(W) x 30(H) x 144.8(D) mm
7-3/8(W) x 1-3/16(H) x 5-11/16(D) inch
Mass
(Monitor unit) ................................................................................................................580 g (1.3 LBS)
(Video box unit) ............................................................................................................730 g (1.6 LBS)
Although the effective pixels for the liquid crystal panel is given as 99.99% or more, 0.01% of pixels may not light or
may light incorrectly.
