17
Preparations
L
VIDEO 1
R A L C L R
L R B
PLAY IN REC OUT PLAY IN
MONITOR OUT VIDEO 1 DVD
R
75µs
AM 10kHz
FM 100kHz
50µs
AM 9kHz
FM 50kHz
DE-
EMPHASIS
CHANNEL
SPACE
FRONT SPEAKERS CENTER SPEAKER
FRONT SPEAKERS
SURROUND SPEAKERS
RED BLUE GREEN
GRAY ORANGE
+
-
+
-
FRONT
SPEAKERS
CENTER
SPEAKER
RED BLUE GREEN
+
-
+
-
SURROUND
SPEAKERS
(8 — 16 Ω)
SUB WOOFER
SPEAKER
(8 — 16 Ω)
GRAY ORANGE BROWN
+ +
SURROUND SPEAKERS
(8 — 16 Ω)
GRAY ORANGE
SW
FRONT SPEAKERS CENTER SPEAKER
RED BLUE GREEN
SUB WOOFER
PRE OUT
Setting up the system
Right
Front Speakers A
Right
Left
(Be sure to connect both
surround speakers)
Center
Speaker
Surround Speakers
Powered
subwoofer
Connecting the speakers
The VR-505/517/KRF-V5050D/V5550D are equipped with one-touch
speaker terminals.They are arranged in the same manner as the speaker
terminals of the VR-506/KRF-V6050D. Refer to the instructions on
making connections to the VR-506/KRF-V6050D when making con-
nections to the VR-505/517/KRF-V5050D/V5550D.
VR-517/KRF-V5550D VR-505/KRF-V5050D
VR-506/KRF-V6050D
VR-517/KRF-V5550D
VR-505/KRF-V5050D
Use the FRONT SPEAKERS
B terminals if you want to
connect a second front
speaker system (for VR-506/
KRF-V6050D).
VR-506/KRF-V6050D
Left
(Except
VR-517/
KRF-V5550D)
