Installation
10
Mounting
CAUTION: This unit is sealed. The cover is not removable!
• Remove the mounting plate from the back of the alarm by
holding the mounting plate and twisting the alarm in the
direction indicated by the “OFF” arrow on the alarm cover.
• After selecting the proper smoke alarm location as described
previously, and wiring the AC Quick-Connect wire harness as
described in Wiring Instructions, attach the mounting plate to
the electrical box (Image 4B).
A
A
IMAGE 4A
IMAGE 4C
IMAGE 4D
“A” LINE
ALIGNMENT MARKS
WALL MOUNTING
POSITION
ROTATE TO MOUNT OR
TO REMOVE
IMAGE 4B
Install
Remove
