Keys Fitness Power System 1850 - Manual (Page 11)

Assembly
11
STEP 2
Attach the Seat Pad Support Receptacle (2) to Rear Base (1) and secure in place using three Nylon Locknuts
(104), six Washers (102), and three Bolts (94).
Connect the Front Upright (86) to Seat Pad Support Receptacle (2) and secure together using two Nylon
Locknuts (104), four Washers (102), and two Bolts (95).
Insert the Pec Dec Mount (7) onto Seat Pad Support Receptacle (2) using two Nylon Locknuts (104), four
Washers (102), and two Bolts (94) on the side. Next, insert one Washer (107), one Spring Washer (103), and
one Bolt (93) at the top.
Figure 2
