4 5
User Guide User Guide
2. Component Name 3. Function of Each Component
■ Fixed focus lens
• Fixed focus lens installed on the camera.
Please take cautions that any dust or foreign
matter gathers on the front glass surface of the
lens.
■ Main body
• A body that supports the camera.
■ PCB board
• This part is quite important since it performs
the camera function. Please handle with care.
■ Power cable
• The terminal that is connected to the power
(adaptor) cable. Connect to DC 12V/AC 24V.
■ Video signal output cable
• The cable that sends the video signal.
■ Dome cover
• The transparent plastic cover that protects the
camera.
Be careful not to make a scratch on it.
E
Video cable
Dome cover
Fixed focus lens
PCB board
Main body
Power cable
