Page 38
39
Wiring Two or More DIRECTV HD Receivers
Continued...
F
+
–
+
–
SATELLITE IN
OUT TO TV
TV ANT/CABLE IN
AUDIO
VIDEO
S-VIDEO
PHONE JACK
R
L
SATELLITE IN
HDTV
Converter
(02-1431)
HDTV
CONTROL
ANTENNA UNIT
RF PORT
TONE
DETECT
FUSE
POWER IN
+ / –
MCP
HD Receiver #2
HD Receiver #1 (Primary)
SATELLITE IN
OUT TO TV
TV ANT/CABLE IN
AUDIO
VIDEO
S-VIDEO
PHONE JACK
R
L
SATELLITE IN
RF2
RF1
This receiver controls
satellite selection
Antenna
Splitter
(19-0366)
Switchplate
+12 VDC
+
–
+12 VDC
Power
Data
LHCP
+18V
RHCP
+13V
+12 VDC
Multiswitch
Additional HD or
Standard Receivers
OUT
OUT
INPUT
