Page 34: Appendix
35
This appendix provides system wiring diagrams
for the following receiver configurations:
• One or two receivers
• Three or more receivers (circular only)
• One DIRECTV HD receiver
• Two or more DIRECTV HD receivers
The wiring diagrams on the following pages
are intended as a quick reference only. Be
sure to follow the complete wiring
instructions provided earlier in this manual.
IMPORTANT!
Wiring Diagrams
F
Appendix
