Specifications
Chapter Four : Warnings and Specifications
IR Receiver In
IR OUT LCD
REMOTE
To Tip Signal Signal
To Ring Ground
To Sleeve +12V Ground
Terminal
Video Section
Video Inputs / Outputs
Video (composite) ............................................. 1 Vp-p / 75 Ω
S Video (luminance signal) ............................... 1 Vp-p / 75 Ω
(chrominance signal) .................. 0.286 Vp-p / 75 Ω
Component (luminance signal) ....................... 1 Vp-p / 75 Ω
(P B /P R -signal) ............................. ±0.324 Vp-p / 75 Ω
FM Tuner Section
Tuning Frequency Range ........................... 87.5 MHz ~ 108 MHz
Usable Sensitivity (Mono)
.................... 1.6 µ V (75 Ω ) / 15.2 dBf (75 kHz dev., sinad 30 dB)
50dB Quieting Sensitivity
Stereo ................................................ 31.6 µ V (75 Ω ) / 41.2 dBf
Total Harmonic Distortion (1 kHz)
Mono ...................................................... 0.3 % (65 dBf input)
Stereo ...................................................... 0.7 % (65 dBf input)
Signal to Noise Ratio (1 kHz, 75 kHz DEV.)
Mono ...................................................... 75 dB (65 dBf input)
Stereo ...................................................... 68 dB (65 dBf input)
Stereo Separation (1 kHz) ................................................. 38 dB
Selectivity (+400 kHz) ....................................................... 70 dB
Frequency Response ................ 30 Hz ~ 15 kHz, +0.5 dB, -3.0 dB
AM Tuner Section
Tuning Frequency Range
10kHz step ............................................. 530 kHz ~ 1,700 kHz
Usable Sensitivity (30 % mod., S/N 20 dB)
........................................................................... 16 µ V / (600 µ V/m)
Signal to Noise Ratio (30 % mod. 1 mV input) ............... 50 dB
Relay and IR In/Out Section
Relay Control Terminal
Maximum Output Current ............................................ 20 mA
Operating Voltage .............................................................. 12 V
Output Impedance .......................................................... 470
Ω
IR Receiver In Terminal
Maximum Output Current ............................................ 20 mA
Operating Voltage .............................................................. 12 V
Output Impedance .......................................................... 470
Ω
IR Out LCD Remote Terminal
Maximum Output Current ............................................ 20 mA
Operating Voltage ................................................................ 5 V
Output Impedance .......................................................... 470
Ω
IR Repeater Control Terminal
Maximum Output Current ............................................ 20 mA
Operating Voltage .............................................................. 12 V
Output Impedance .......................................................... 470
Ω
SHAPE OF PLUG TO BE CONNECTED:
IR IN/OUT SPECIFICATION:
RELAY CONTROL SPECIFICATION:
General
Power consumption ............................................................ 5.1 A
AC outlet
Switched ...................................... 2 (total 90 W, 0.75 A max.)
Dimensions ................................................ W : 480 mm (18-7/8”)
H : 191 mm (7-1/2”)
D : 416 mm (16-3/8”)
Weight (Net) ........................................................ 18 kg (39.7 lb)
To Tip 0V 0V +12V
To Ring 0V +12V +12V
To Sleeve Ground Ground Ground
Power On
and when
switched to
Video Input
Power
Off Power
On
status
IR Receiver In and IR Out
LCD Remote IR Repeater Out
Stereo mini plug Mono mini plug
Sleeve Sleeve
Ring
Tip Tip
Kenwood follows a policy of continuous advancements in
development. For this reason, specifications may be changed
without notice.
Full performance may not be exhibited in extremely cold
locations (below 0 deg. C).
