FIRST INSTALLATION: Single-cable system (Automatic)

AUTOMATIC

Secure channel with PIN:

Press the

button to switch to the “Secure channel with PIN” line. Here it is possible to protect the

transmission frequency used by entering a PIN. No other receiver can then use that transmission frequency

unless the PIN is entered. Select the “Yes” setting using the

buttons.

Password PIN (only for “Yes” setting in the “Secure channel with PIN” line):

Select the “Password PIN” line using the

button. You can now use the number pad to enter

a PIN (0-255).

Testing connection:

Use the

button to switch to the “Test connection” line and press the

button. The receiver now

tests the settings you have made. The following message appears:

Select a spare transmission frequency using the

buttons and then confi rm your selection

using the

button. The following display appears:

You can only use the
“Secure channel with
PIN” function if this
function is supported
by the single-cable
components used. In
the case of Kathrein

single-cable components, this
is currently only the case for the
EXU 908.
