English
|
29
Screwing the Faceplate on the Unit
If you want to fasten the faceplate to the main
unit so that it does not fall off.
1
Refer to the section frame> (page 30) and then remove the hard 2 Drop open the faceplate by pressing the Release button. 3 Tighten the stepped screw (Accessory 5) in the hole shown on the diagram. Accessory 5 4 Tighten the screw (ш2 Ч 5 mm) (Accessory 6) and bracket (Accessory 7 ) in the hole shown on the diagram. Accessory 6 Accessory 7 5 Tighten the screw (ш2 Ч 5 mm) (Accessory 6) and bracket (Accessory 8) in the hole shown on the diagram. Accessory 6 Accessory 8 • Never insert the screws in any other screw hole than the one specified. If you screw them in another hole, it will Accessory 5 ..........1 Accessory 6 ..........2
rubber frame.
contact and may cause damage to the mechanical parts
inside the unit.
