Rear view navigation system (optional) – Kenwood DDX7017 User Manual
Page 5
English
|
5
+
+
+
+
FRONT L
FRONT R
REAR L
REAR R
ANT. CONT
P CONT
EXT.CONT
REVERSE
ILLUMI
REMO.CONT
MUTE
IConnection cable
(Included in the
Navigation system)
Connection cable
(Included in the TV tuner)
Wiring harness
(Accessory
1)
To front left speaker
Wiring harness
(Accessory
2)
Rear view
Navigation System
(Optional)
To front right speaker
To rear left speaker
To rear right speaker
White/Black
White
Gray/Black
Gray
Green/Black.
Green
Purple
Purple/Black
