15
Overlay Series Door Handle Kits
The following handle styles are available. Contact your KitchenAid
dealer or KitchenAid Parts and Accessories at
1-800-442-9991. In Canada, call 1-800-807-6777.
Handles
These handles can be installed on side-by-side and bottom-
freezer refrigerators that require overlay panels.
*Available for non-dispensing models only.
Standoffs
The kit includes screws to support ³/₄" applications.
Standoffs can be installed on side-by-side and bottom-freezer
refrigerators that require overlay panels.
NOTES:
■ Two standoffs must be ordered for each handle.
■ Handles and standoffs may be combined to meet your
individual decorating needs.
Architect ® Series
Handles
Classic Series Factory Panels and Kits
All factory parts are available through your KitchenAid dealer or by
calling KitchenAid Parts and Accessories at 1-800-442-9991. In
Canada, call 1-800-807-6777.
Factory Door Panel Kits
Three kits containing colored acrylic or stainless steel door and
top grille panels are available. Follow the kit instructions for
installing the panels.
NOTE: Panel kits are not required for factory-installed stainless
steel panel models.
Door Panel Part Numbers for Non-dispenser Models
Door Panel Part Numbers for Dispenser Models
Extended Door Handle Kits
Use extended door handles when additional finger clearance is
needed between the door handles and custom panel. Follow the
kit instructions for installing the door handles.
A. Architect ® Series handle (4396103)
B. Flat end straight handle (4396776) with stainless
steel clamshell standoffs (4396775)
C. Round end arc handle (4396779) with bronze bullet
standoffs (4396778)
D. Round end semicircle (4396777) with stainless steel
cylinder standoffs (4396782)
PART NO. DESCRIPTION
4396776 Flat End Straight - 21" (53.3 cm) Length,
Satin Stainless Steel
4396781 Flat End Straight - 45" (114.3 cm) Length,
Satin Stainless Steel
4396777 Round End Semicircle,
Satin Stainless Steel*
4396779 Round End Arc,
Satin Stainless Steel*
PART NO. DESCRIPTION
4396775 Clamshell, Satin Stainless Steel
4396780 Clamshell, Satin Bronze
4396774 Bullet, Satin Stainless Steel
4396778 Bullet, Satin Bronze
4396782 Cylinder, Satin Stainless Steel
4396773 Cylinder, Satin Bronze
A B C D
PART NO. COLOR
4396103 Stainless Steel
8171760 Biscuit
4396105 White
4396106 Black
Color 36 42 48
White #2325136 #2325137 #2325138
Black #2325139 #2325140 #2325141
Stainless Steel #2325142 #2325143 #2325144
Color 36 42 48
White #2325127 #2325128 #2325129
Black #2325130 #2325131 #2325132
Stainless Steel #2325133 #2325134 #2325135
Color Part Number
White #4387990
Black #8171418
Stainless Steel #4388062
Matte Aluminum #4387989
