30
C-V351/C-V301 (EN)
Searching for a desired program type
(PTY search)
1
2
PTY
Tuner
ENTER
ENTER
ENTER
RDS
1 2 3
4 5 6
7 8 9
0 +10
ENTER
TUNING
PTY SELECT
RDS
RDS Display
TA /News / Info.
1 2 3
4 5 6
7 8 9
0 +10 +10
PTY
RDS (Radio Data System)
Main operation menu
By specifying the type of program (genre) you want to listen
to, the tuner automatically searches for a station which is
currently broadcasting a program of the specified type.
Preparation
With certain receiving conditions, it may take more than
1 minute until the search completes.
÷ Preset RDS stations with the AUTO
MEMORY function.
÷ Select the TUNER input.
÷ Set the receiving band to FM.
Select the PTY search mode.
When an RDS broadcast is received, the program type is shown on
the display. If no PTY data is available, or if the station is not an RDS
station, “NONE” is displayed.
Select the desired program type.
Use program type table on the right for your convenience.
A When selecting with the up or down keys
Next
programme
type Previous
programme
type
Next
programme
type Previous
programme
type
The up or down key allows to select desired programme types from
the 29 types. Press and hold the key and release it when the desired
type is displayed.
Select while “PTY” is lit.
The numeric keys allow to select the desired one of programme
types 1 to 0 directly. If you want to select other programme type than
them, use the TUNING key.
B When selecting with the numeric keys
B Program Type Name Display
1 Pop Music POP M
2 Rock Music ROCK M
3 M.O.R. Music M.O.R. M
4 Light Classic Music LIGHT M
5 Serious Classic Music CLASSICS
6 Other Music OTHER M
Weather WEATHER
Finance FINANCE
Children’s programmes CHILDREN
Social affairs SOCIAL A
Religion RELIGION
Phone in PHONE IN
Travel TRAVEL
Leisure LEISURE
Jazz Music JAZZ
Country Music COUNTRY
National Music NATION M
Oldies Music OLDIES
Folk Music FOLK M
Documentary DOCUMENT
7 News NEWS
8 Current Affairs AFFAIRS
9 Information INFO
0 Sport SPORT
Education EDUCATE
Drama DRAMA
Cultures CULTURE
Science SCIENCE
Varied Speech VARIED
A
Program type table
*
*M.O.R. Music (Middle of the Road Music)
( )
DOWN
( )
UP
“NO DATA” is displayed if this operation is attempted
before performing the AUTO MEMORY operation.
Main unit GRC
RC GRC
RC GRC
+10
5 4 3 2 1
0 9 8 7 6
PTY SEARCH
A B
PTY
fi
N E W s RDS
EON
PTY
TIMER
NEWS
INFO.
FM
AM
LW
MW
TA TP
1 2
MEMO
1
2
