Page 2
OVEN PARTS
2
For Model:KDRP487MSS03
(Stainless Steel)
8186197
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
Literature Parts
8302571 Installation
Instructions
8301284 Use & Care Guide
8302546 Tech Sheet
9759441 Conversion
Instructions
3191638 Safer Cooking Tips
2
4449809 Screw, 8−18 x 3/8
3
8301573 Bracket, Control
Support
4
8302394 Bracket, Control
(Left Side)
5
8301574 Bracket, Control
(Right Side)
6
4452260 Spacer, Foam
7
8302191 Top, Chassis
8
4448520 Bumper, Door
9
4452158 Tube, Vent
10
4452163 Lens, Light
11
4448972 Oven Light Assy
4449748 Screw
12
4452164 Bulb, Light
13
Hinge Receiver
4455605 Left Hand
4455606 Right Hand
14
4455610 Frame, Front
15
4455380 Gasket, Door
16
Control, Zodiac
8301182 (Assist, Rt Side)
8301583 (Assist Lft Side)
17
8301254 Filler, Rear
18
4452152 Bracket, Mounting
19
4451476 Support, Insulation
21
4455510 Bracket, Support
22
4457204 Support, Wiring
3400099 Screw
23
8301159 Channel, Support
24
9759525 Latch, Motorized
25
4455641 Side, Chassis
26
4452232 Back, Chassis
27
Liner, Oven
(Not serviceable)
29
4455636 Sensor
30
4449154 Screw, 8−32 x .440
31
4449040 Screw, 8−18 x 3/8
32
3196176 Screw, 8−18 x 1/2
33
4457319 Vent, Bottom Lower
4449809 Screw
34
8300825 Insulation,
Bottom Vent
37
9759242 Thermostat (TOD)
(Temp.) SPST
43
8302289 Base, Chassis
49
4448933 Retainer, Gasket
50
4451747 Cover, Back
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449314 Insulation, Wrap
4450363 Insulation, Back
