OPTIONAL PARTS
10
For Model:KDRP487MSS03
(Stainless Steel)
8186197
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
4453192 Seal, Ribbon
Cable
4453191 Seal, Access
Panel
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
4448444 Grommet, Rail
Harness, Wire
(Main)
8302551 Right Side
8302552 Left Side
8301196 Jumper Harness
8301582 Harness, Control
Master
4456628 Harness, Wire
(Ignitor 42")
4456627 Harness, Wire
(Ignitor 28")
8302555 Harness, Wire
(Spark Module)
3191506 Bushing, Conduit
1129449 Bushing
8302522 Conduit
4449809 Screw
112432 Nut
4450800 Screw, Ground
4454835 Tie, Cable
4452222 Spacer, Harness
Miscellaneous
814381 Pin Hinge Kit
8301282 Conc. Kit (LP)
4453141 Bracket, Anti−Tip
4453202 Bracket, Anti−Tip
8301858 Pan, Griddle
8301939 Pan, Roasting
