Quick Start
This section shows the basic operation (projector connecting with the video equipment).
For details, see the page described below for each step.
Setup and Projection
In this section, connection of the projector and the video equipment is explained using one ex-
ample.
3. Remove the lens cap and turn the projector on
2. Connect the projector to the video equipment and plug the power
cord into the AC socket of the projector
On the
projector
On the remote
control
KEYSTONE button
INPUT buttons
STANDBY/ON
button
HEIGHT
ADJUST lever
Focus ring
STANDBY button
_PP. 22–28
_P. 28
5
3
8
3
7
5
8
6
6
ON button
INPUT 4 button
1. Place the projector facing a wall or a screen _P. 18
Zoom ring 6
AC socket
To INPUT 4 terminal
ENTER button
7 Adjustment buttons
(P/R/O/Q)
7
Connect the audio output of
any video devices to an
appropriate audio device.
